Released on Pi Day by the Raspberry Pi Foundation, the model B+ is the second version in the Raspberry Pi 3 Series. The model B+ went through a PCB redesign incorporating a new "System-On-Chip" package, a 200 MHz processor speed increase and Gigabit Ethernet over USB 2. It also has improved WiFi compliance and is now officially classified as a Dual-Band Radio Module.
Over the past 3 years, the Raspberry Pi has undergone a 30+ percent performance boost through firmware, hardware & software optimisations. The new PCB Design & SoC Packaging of the Raspberry Pi 3 B Plus has significantly improved heat distribution over the first version. However, active cooling is still very important because of the 200 MHz processor speed overclock and the fact it uses twice as much current when running at full cpu load.
If you enjoy our videos, then please Like & Share. Our channel is updated every week so hit the Subscribe button to get the newest videos.
- Memory — 1GB LPDDR2 SDRAM
- Storage — Micro SD Slot
- Display — DSI Port
- Power — 5V 2.5A DC Input
- HDMI — Full Size Port
- Camera — CSI Port
- Audio Video — 4 Pole Stereo Composite
- USB — Four 2.0 Ports
- GPIO — Extended 40 Pin Header
- Physical Size — 85mm x 56mm x 17mm
- Pricing — $35.00
- Board — New SoC Package & PCB Design
- Processor — Broadcom BCM2837B0 Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
- Network — Gigabit Ethernet over USB 2.0
- Power — Separate 4-Pin PoE HAT
- Startup — Improved PXE & USB Boot
- Wireless — Dual Band 2.4GHz & 5GHz 802.11.b/g/n/ac , Bluetooth 4.2 BLE
- Cooling — Improved Heat Distribution
- Processor — 200 Mhz Speed Increase
- Network — 300 Mbps Limit
- Wireless — 100 Mbps Limit
- Load Power — 300+ mA
- Idle Power — 170+ mA
